How to Attach Source Evidence to AI Workflow Outputs

I am building TryUncle, an AI agent that watches the screen and annotates it live. That makes one design question hard to ignore: when a workflow produces a value, can a reviewer see why that value is there without opening a trace dashboard?

The useful unit is not a citation at the end of an answer. It is a field-level evidence packet that travels with the output.

Here is the artifact result first. I ran the dependency-free Python 3.9 fixture included below on 2026-08-23.

Test	Observed result
Happy-path reconstruction	pass
Missing evidence	pass
Stale evidence	pass
Contradictory evidence	pass
Unauthorized evidence	pass
Replayable export	pass

The smallest useful evidence packet

Put the value and its proof in the same record. A reviewer should not have to join an output table to a second citation table by guessing which row belongs to which field.

The packet needs five layers:

Layer	Minimum fields	Reviewer question
Run	run_id, created_at, schema_version	Which execution produced this packet?
Source	source_id, URI or governed reference, version, fetched_at, allowed, content_hash	Which source representation was available, and may this workflow use it?
Output field	value, status, evidence[]	What did the workflow return, and is it supported?
Evidence link	source_id, page or start and end, observed_value	Where exactly did this value come from?
Review state	validation results, unresolved questions, reviewer status	What still needs a human decision?

This shape follows a useful distinction in the W3C provenance model: an output is an entity produced by an activity that used other entities. The names in your application can differ, but the chain should remain explicit (W3C PROV Primer).

Here is a complete sample packet with two extracted fields:

{
  "schema_version": "evidence.packet.v1",
  "run_id": "run-001",
  "created_at": "2026-08-23T12:00:00Z",
  "workflow": {"name": "invoice-extract", "version": "1.4.0"},
  "sources": [
    {
      "source_id": "doc-17",
      "uri": "s3://governed/invoice-17.pdf",
      "version": "2026-08-20",
      "fetched_at": "2026-08-22",
      "allowed": true,
      "pages": [1, 2],
      "content_hash": "sha256:fixture"
    }
  ],
  "output": {
    "vendor": {
      "value": "Northwind",
      "status": "supported",
      "evidence": [{"source_id": "doc-17", "page": 1, "start": 0, "end": 18, "observed_value": "Northwind"}]
    },
    "total": {
      "value": 1250.0,
      "status": "supported",
      "evidence": [{"source_id": "doc-17", "page": 2, "start": 40, "end": 57, "observed_value": 1250.0}]
    }
  },
  "validation": [
    {"check": "currency", "result": "pass"},
    {"check": "line_items_sum", "result": "pass"}
  ],
  "unresolved_questions": [],
  "review": {"status": "pending", "required": true}
}

Use JSON Schema to make the required shape machine-checkable. JSON Schema is designed to describe JSON instances and apply constraints such as required properties and data types (JSON Schema getting started guide). Keep semantic checks, such as whether the evidence actually supports the value, in a separate validator. A schema can require evidence; it cannot decide whether a page quote entails a number.

Why evidence belongs beside each field

Document-level citations are useful for navigation. They are weak evidence for extraction because one document can contain ten prices, several dates, and a correction in a footnote.

Attach evidence to the narrowest unit a reviewer may accept or reject. For an invoice, that usually means a field. For a classification, it may mean the label and the span that triggered it. For a summary, it may mean a sentence or claim.

The source ID should be opaque. Let the model select doc-17, not invent a URL or a page number. Your resolver maps doc-17 to the governed source record and checks the location. This turns a made-up citation into a detectable validation error.

Use the selector that matches the source:

Source	Evidence location
PDF	1-indexed page plus optional text span or quote
Plain text	Character start and exclusive end, plus an optional exact quote
HTML	Stable element or fragment plus a text quote and source version
Image or scan	Page plus bounding box, OCR text, and extraction version
Database row	Table or record ID, column, and snapshot version

The W3C Web Annotation model defines text quote selectors with exact text, prefix, and suffix, and position selectors with inclusive start and exclusive end positions. It also warns that position selectors are brittle when the resource changes, which is why the packet stores version and content_hash too (Web Annotation Data Model). Provider APIs make similar distinctions. Anthropic documents PDF page ranges, plain-text character ranges, and custom-content block ranges for citations (Claude citations documentation).

Make freshness and authorization part of validation

Do not treat a resolvable source as an admissible source. A source can exist, be easy to fetch, and still be too old or outside the workflow's permission boundary.

At minimum, validate these conditions before a packet reaches a reviewer:

1. Every source_id resolves to exactly one source record.
2. Every source record is authorized for this workflow and tenant.
3. Every page, span, row, or bounding box is valid for the recorded source version.
4. Every supported field has at least one evidence link.
5. Evidence links for the same field do not report conflicting observed values.
6. The source is inside the freshness window, or the field is explicitly marked stale.
7. Failed validation checks and unresolved questions remain in the export.

Google's grounding response model connects response segments to grounding chunks, source URIs, byte offsets, and, in some versions, confidence scores. Its grounding check also distinguishes cited chunks from claim-to-citation links and treats partially entailed claims as ungrounded (Google GenerateContentResponse, Google grounding check). That is the right mental model: a confidence number can support triage, but it cannot replace a resolvable source binding.

If a field has no admissible evidence, do not silently return the value as supported. Return a value with status: "missing" or status: "blocked", keep the unresolved question, and stop the downstream action when the field is required.

Give the reviewer a compact decision view

The reviewer does not need every parser event first. They need the output, status, source location, and next decision in one row.

The fixture renders this view from the sample packet:

vendor | Northwind | supported | doc-17 p.1
total | 1250.0 | supported | doc-17 p.2
unresolved_questions | none

For a real packet, add the validation summary and an action column:

Field	Value	Status	Evidence	Next action
vendor	Northwind	supported	doc-17 p.1	accept
total	1250.0	contradicted	doc-17 p.2, doc-18 p.2	resolve source conflict
due_date	null	missing	none	request document or escalate

Use status as a controlled vocabulary. supported means evidence exists and checks pass. stale means evidence resolves but is outside policy. contradicted means admissible evidence disagrees. blocked means the source is not authorized. missing means no usable evidence was attached. These states should drive workflow routing, not just badge colors.

Run source-binding tests before release

The following Python 3.9 script uses only the standard library. It builds the sample packet, mutates one failure at a time, validates the packet, renders the reviewer rows, and checks that the exported JSON can be replayed.

from copy import deepcopy
from datetime import date
import json

TODAY = date(2026, 8, 23)
STALE_AFTER_DAYS = 30

def packet():
    return {
        "schema_version": "evidence.packet.v1", "run_id": "run-001",
        "created_at": "2026-08-23T12:00:00Z",
        "workflow": {"name": "invoice-extract", "version": "1.4.0"},
        "sources": [{
            "source_id": "doc-17", "uri": "s3://redacted/invoice-17.pdf",
            "version": "2026-08-20", "fetched_at": "2026-08-22",
            "allowed": True, "pages": [1, 2], "content_hash": "sha256:fixture"
        }],
        "output": {
            "vendor": {"value": "Northwind", "status": "supported", "evidence": [
                {"source_id": "doc-17", "page": 1, "start": 0, "end": 18, "observed_value": "Northwind"}
            ]},
            "total": {"value": 1250.0, "status": "supported", "evidence": [
                {"source_id": "doc-17", "page": 2, "start": 40, "end": 57, "observed_value": 1250.0}
            ]}
        },
        "validation": [{"check": "currency", "result": "pass"}],
        "unresolved_questions": [], "review": {"status": "pending", "required": True}
    }

def validate(p):
    errors, sources = [], {s["source_id"]: s for s in p["sources"]}
    for field, item in p["output"].items():
        evidence = item.get("evidence", [])
        if not evidence:
            errors.append(f"{field}: missing evidence")
            continue
        if len({json.dumps(e.get("observed_value"), sort_keys=True) for e in evidence}) > 1:
            errors.append(f"{field}: contradictory evidence")
        for e in evidence:
            source = sources.get(e.get("source_id"))
            if not source:
                errors.append(f"{field}: unknown source")
                continue
            if not source["allowed"]:
                errors.append(f"{field}: unauthorized source {source['source_id']}")
            age = TODAY - date.fromisoformat(source["fetched_at"])
            if age.days > STALE_AFTER_DAYS:
                errors.append(f"{field}: stale source {source['source_id']}")
            if e.get("page") not in source.get("pages", []):
                errors.append(f"{field}: invalid page reference")
    if any(v["result"] != "pass" for v in p["validation"]):
        errors.append("validation: failed check")
    return errors

def reviewer_view(p):
    rows = []
    for field, item in p["output"].items():
        refs = ", ".join(f"{e['source_id']} p.{e['page']}" for e in item.get("evidence", [])) or "none"
        rows.append(f"{field} | {item['value']} | {item['status']} | {refs}")
    rows.append("unresolved_questions | " + ("; ".join(p["unresolved_questions"]) or "none"))
    return rows

checks = {}
happy = packet()
checks["happy_path"] = not validate(happy) and len(reviewer_view(happy)) == 3
missing = deepcopy(happy)
missing["output"]["total"]["evidence"] = []
checks["missing_evidence"] = "total: missing evidence" in validate(missing)
stale = deepcopy(happy)
stale["sources"][0]["fetched_at"] = "2026-06-01"
checks["stale_source"] = "total: stale source doc-17" in validate(stale)
contradictory = deepcopy(happy)
contradictory["sources"].append({**contradictory["sources"][0], "source_id": "doc-18"})
contradictory["output"]["total"]["evidence"].append(
    {"source_id": "doc-18", "page": 2, "start": 40, "end": 57, "observed_value": 1300.0})
checks["contradictory_evidence"] = "total: contradictory evidence" in validate(contradictory)
unauthorized = deepcopy(happy)
unauthorized["sources"][0]["allowed"] = False
checks["unauthorized_source"] = "vendor: unauthorized source doc-17" in validate(unauthorized)
exported = json.dumps(happy, sort_keys=True, indent=2)
checks["replayable_export"] = json.loads(exported) == happy
assert all(checks.values()), checks
print(json.dumps({"tests": {k: "pass" for k in checks},
                  "reviewer_view": reviewer_view(happy),
                  "export_round_trip": "pass"}, indent=2))

The script checks source binding, not truth in the abstract. Add domain checks for totals, dates, units, required fields, and semantic entailment. Keep those results in the packet so a reviewer can tell the difference between “the model returned a value,” “the value matched a source span,” and “the value passed a business rule.”

This is also where provider adapters belong. Some APIs return citations as interleaved response blocks and do not allow them inside strict structured output. Keep the provider response as an input to your resolver, then emit your own packet contract. Your workflow should not make the reviewer learn six provider-specific citation formats.

Before you ship, replay the export with the source resolver unavailable. If the packet still identifies the source version, location, validation outcome, and unresolved questions, the reviewer has a durable record. If it only contains a URL and a confidence score, it is a pointer, not evidence.

For the broader run-level record, see How to Add an Audit Trail to an AI Workflow. For the scope decision that precedes this implementation, start with How Do I Scope an AI Agent Proof of Concept?, then use How to Evaluate an AI Agent when this evidence gate becomes part of a release decision.

If your team is deciding what to build first, Marius Manolachi's AI product coaching and consulting is the next step. The useful handoff is the packet, the tests, and the unresolved questions, not a polished screenshot.
